Square Wave® TIG 200 TIG Welder
K5126-1
Square Wave TIG 200 welder for AC/DC stick and TIG welding uses Square Wave Technology.
Rebate
$600 End User Rebate (US Only) - See Details Below - Offers valid for a limited time only, while supplies last
MSRP
USD $2,499.00/EA
Lincoln Electric Business Partner?
Sign in to view your priceDETAILS
LIMITED-TIME OFFER (US Only)!Buy a Square Wave® TIG 200 Welder and receive a $600 VISA gift card rebate.STACK & SAVE - Add Lincoln Electric Accessories & Filler Metals for more savings.
SUBMITTING IS AS EASY AS…
- Go To: lincolnrebates.com
- Complete Account Registration
- Click ‘SUBMIT A CLAIM’
- Select You Rebate and Enter Machine Serial Number
- (For Additional Stack & Save Rebates) Circle the Accessories and Filler Metals on Your Invoice or Receipt with Price Paid.
- Click ‘COMPLETE MY CLAIM’
View All Buy Red Save Green Rebates
SIMPLICITY WITHOUT COMPROMISE
The Square Wave® TIG 200 is a portable TIG and stick welding machine that lets hobbyists, makers, small fabricators and craftsmen explore their creativity.
It is designed to help expand your welding expertise. As your skills and confidence grow, you can take advantage of the Square Wave TIG 200’s additional functionality. No matter your skill level, you won’t be disappointed.
The Square Wave TIG 200 provides smooth and stable AC TIG welding on aluminum and DC TIG welding on steel, stainless steel and chrome-moly.
A user-friendly interface enables the operators to set it, forget it and weld.
ADVANCED FEATURES YET EASY TO USE
The user interface makes machine setup easy. Available features, such as Pulse, which provides a drumbeat-like rhythm for filler metal deposition, make you become a better TIG welder - faster.
- A Great TIG Machine for Aluminum - For a wider or tighter welding bead, users can easily adjust AC Frequency Control. AC Balance can be adjusted to provide more cleaning action on dirty aluminum or to maximize penetration on thick materials.
- TIG and Stick from One Power Source - The multi-process machine can TIG weld when precision and bead appearance are important. Users also have the advantage of stick welding capability for outdoor work or thicker materials.
- Take it Everywhere, Plug in Anywhere.™ - Plug in the Square Wave TIG 200 where you need it - a standard 120V circuit or 230V for maximum output. Portable and convenient to use, only 46 lb (21 kg).
Disclaimers
Service Information
What's Included
- (1) Square Wave TIG 200 TIG Welder
- (1) K1782-14 PTA-17 TIG Torch Ready-Pak®
- (1) K870 Foot Amptrol™
- (1) Gas Regulator/Flowmeter and 10 ft (3 m) Gas Hose Kit
- (1) Stick Electrode Holder 200A
- (1) Ground Clamp and Cable
- (1) 120 and 230V Input Cords
You May Also Need
Specifications
Product Weights & Dimensions
| Dimensions (H x W x D) | 14 in x 10.75 in x 19.25 in (358 mm x 282 mm x 502 mm) |
| Net Weight | 46.5 lbs (21.092 kg) |
Machines
| Max Rating | 200 |
| Work Lead Connector Type | Dinse |
Basic Specification
| Input Voltage | 120/230 |
| Input Current | 120V TIG: 25% Duty Cycle 21A 40% Duty Cycle 17A, 60% Duty Cycle 14A, Stick: 20% Duty Cycle 19A 60% Duty Cycle 16A 230V TIG: 25% Duty Cycle 22A 40% Duty Cycle 17A 60% Duty Cycle 13A |
| Input Hertz | 50/60 |
| Input Power | 120/230/1/50/60 |
| Input Phase | 1 |
| Mode Icon | CC |
| Output Range | 120V TIG: 10-125A, Stick: 10-90A, 230V TIG: 10-200A, Stick: 10-170A |
| Polarity | AC/DC |
| Rated Output | 120V TIG: 125A/25%, 100A/40%, 85A/60%, 120V Stick: 75A/20%, 65A/60% 230V TIG: 200A/25%, 160A/40%, 130A/60% Stick: 170A/20%, 100A/60% 120V AC TIG: 110A/25% |
Application
| Typical Application | Automotive Brewery Distillery General Fabrication Maintenance & Repair |
Warranty
| Warranty | 3 Years |
